Equipment model

G90

Maximum lifting capacity, t

90

Rated lifting weight, t

76.5

Whole machine quality, t

55

Dimensoins of main engine transportation, mm

5630*3436*3540

Transport quality of main engine, t

38.9

Average ground pressure, kPat

86.6

The minimum ground clearance, mm

550

Maximum climbing ability, °

25

Applicable environment, °C

-40 ∽ 60

Model

Cummins NT855-C360

Rated power, Kw

257

Rated speed, r/min

2000

Chassis

Special chassis for pipelayer

Operating mode

Joystick

Theory speed (2 gear), km/h

3.6/6.6

Length of the tack ground, mm

3620

Track center distance, mm

2490

Caterpillar width, mm

860

Number of the supporting wheels

9x2

Form of amplitude variation

Wire rope

Operation mode

Hydraulic control handle

The length of the boom, mm

8600/9600/10500

Maximum lifting height, mm

7050/8110/8970

Angle of amplitude variation, °

0∽86

Speed, m/min

0∽7.0(8 times)

Time of the amplitude variation, s

40 (5 times)
